Objectives

The objectives of the current stack are two-fold:

  • For end users to be able to monitor their compute units in real time. Besides the conventional metrics like CPU usage, memory usage, etc, the stack also exposes metrics like energy consumption and equivalent emissions in real time. The stack is also capable of showing the aggregate usage metrics of a given project/tenant/namespace.

  • For the operators/admins to be able to monitor the usage of the cluster in terms of CPU usage, memory, energy, etc. With the current stack the operators will be able to identify the top consumers of the resources in the cluster, users/projects that are under consuming the allocated resources etc.

CEEMS has been designed to be modular and extensible, i.e., CEEMS is meant to support multiple clusters at the same time. For instance, imagine a Data Center (DC) has a SLURM cluster and a Openstack cluster. A single deployment of CEEMS should be able to consolidate the metrics data of SLURM jobs and Openstack VMs and expose it to end users using a single instance of Grafana.

End user's perspective​

The following screenshots show some of the capabilities of the CEEMS when used with Grafana.

Note

These are only few dashboards build to demonstrate the capabilities of CEEMS and the operators are free to create more dashboards according to their business requirements.

Breakdown of energy usage of different users of a given project during a given period of time​

Resource usage breakdown

Total resource usage of a given user during a given period of time​

User resource usage

List of compute units with their aggregate usage metrics of a given user during a given period of time​

User units

Time series CPU metrics of a given compute unit​

CPU metrics

Time series GPU metrics of a given compute unit​

GPU metrics

Admin's/Operator's perspective​

Resource usage of entire cluster with time​

Global usage

Important

This is an interesting metric as we can clearly see there is a considerable reduction in the emissions even when the overall energy consumption remained the same. This is due to the fact that we use real time emission factors which can be dynamic and a small change in factor can have huge implications in emissions for big data centers.

Resource usage of different projects​

Project stats
